Beadlock wheel real Off-road Black Daytona 8x17 6x139,7 ET-35

Wheel rim anti-Slaling Beadlock Off-road Displaced black daytona, quality metal heavy Duty of great thickness.

Measure 8×17 6×139.7 ET-35. Bushing CB 111 mm

Recommended for tyres with width from 235mm to 285mm.

Wheel rim displaced15cmFrom the bushing to the outer edge

Wheel rim for exclusive use Off-road: Mountain, Triars …

Vehicle list Off-road that per tujeres can serve the wheel rims. Also for protos that use axes of these vehicles

 Ford:

Ford Maverick I [1993 – 1999]Check Measure Bushing, if your bushing measures 100 We recommend buying the Centermeters of wheel rim 111-100

Galloper:

Galloper Exceed [1991 – 2003] It is recommended to buy the centers of wheel rim 111-108 Reference LD-CEN-108

Galloper Super exceed [2000 – 2005] It is recommended to buy the centers of wheel rim 111-108 Reference

Hyundai:

Hyundai Terracan [2001 – 2007] It is recommended to buy the centers of wheel rim 111-106.1 Reference

Hummer:

Hummer H3 [2005 – ] It is recommended to buy the centers of wheel rim 111-108 Reference alone Wheel rim diameter 17 “

Izuzu:

Isuzu Trooper [1998 – ] It is recommended to buy the centers of wheel rim 111-108

Isuzu D-Max/Rodeo [2002 – 2012] It is recommended to buy the centers of wheel rim 111-108

Isuzu D-Max [2012 – ] It is recommended to buy the centers of wheel rim 111-108 Wheel rim diameter 17 “, 18”

Mitsubishi:

Mitsubishi Montero [1982 – 1991] It is recommended to buy the centers of wheel rim 111-108

Mitsubishi Montero V20 [1991 – 1999] It is recommended to buy the centers of wheel rim 111-108

Mitsubishi Montero Sport [1996 – 2008] It is recommended to buy the centers of wheel rim 111-108

Mitsubishi L200 [1996 – 2001] It is recommended to buy the centers of wheel rim 111-108

Mitsubishi L200 [2001 – 2006] It is recommended to buy the centers of wheel rim 111-108

Mitsubishi L200 “Triton” [2006 – 2009] You have to buy also the centers of wheel rim of 111-67.1

Mitsubishi L200 “Triton” [2010 – 2015] You have to buy also the centers of wheel rim of 111-67.1

Mitsubishi Montero V60 [2000 – 2006] You have to buy also the centers of wheel rim of 111-67.1

Mitsubishi Montero V80 [2007 – ] You have to buy also the centers of wheel rim of 111-67.1

Mitsubishi L200 “Triton” [2015 – ] You have to buy also the centers of wheel rim of 111-67.1

Nissan:

Nissan Patrol R240 / 160/260/280 [1982 – 1998]

Nissan Patrol GR Y60 [1988 – 1998]

Nissan Patrol GR Y61 [1998 – 2005]

Nissan Patrol Y61 [2005 – ]

Nissan Navara D22 [2002 – 2005]

Nissan NP300 [2008 – ] Wheel rim diameter 16 “, 17”, 18 “

Nissan Terrano I [1986 – 1995] Check Measure Bushing, if your bushing measures 100 We recommend buying the Centermeters of wheel rim 111-100

Nissan Terrano II [1993 – 1996]Check Measure Bushing, if your bushing measures 100 We recommend buying the Centermeters of wheel rim 111-100

Nissan Terrano II [1996 – 2006] Check Measure Bushing, if your bushing measures 100 We recommend buying the Centermeters of wheel rim 111-100

Opel:

Opel Frontera [1991 – 1998]Check Measure Bushing, if your bushing measures 100 We recommend buying the Centermeters of wheel rim 111-100

Opel Frontera B [1998 – 2004]Check Measure Bushing, if your bushing measures 100 We recommend buying the Centermeters of wheel rim 111-100

Opel Monterey [1992 – 1998] It is recommended to buy the centers of wheel rim 111-108 Reference

Toyota:

Toyota Landcruiser J70 [1983 – 1996] It is recommended to buy the centers of wheel rim 111-108

Toyota Landcruiser J76-78-79 [2007 – ] It is recommended to buy the centers of wheel rim 111-108

Toyota Landcruiser J80 [1992 – 1998] It is recommended to buy the centers of wheel rim 111-108

Toyota 4Runner [1987 – 1995] It is recommended to buy the centers of wheel rim 111-106.1

Toyota Hilux [1997 – 2005] It is recommended to buy the centers of wheel rim 111-106.1

Toyota Hilux “Vigo” [2005 – 2016] It is recommended to buy the centers of wheel rim 111-106.1 Wheel rim diameter 16 “, 17”, 18 “

Toyota FJ Cruiser [2007 – ] It is recommended to buy the centers of wheel rim 111-106.1

Toyota Landcruiser J90 [1996 – 2003] It is recommended to buy the centers of wheel rim 111-106.1 Wheel rim diameter 16 “, 17”, 18 “

Toyota Landcruiser J120 [2003 – 2009] It is recommended to buy the centers of wheel rim 111-106.1 Wheel rim diameter 16 “, 17”, 18 “

Toyota Landcruiser J150 [2009 – ] It is recommended to buy the centers of wheel rim 111-106.1 Wheel rim diameter 16 “, 17”, 18 “

Toyota Hilux “Revo” [2016 – ] It is recommended to buy the centers of wheel rim 111-106.1 Wheel rim diameter 16 “, 17”, 18 “

Attention:

– They can leave the body and require fender flares.

– Certain vehicles may specify additional centering, we have the centers available.

– Applications by brand indicated in a guideline, it is recommended to verify that the mount, displacement, bushing and fixings they are suitable for your particular vehicle.

⚠️ Critical assembly guide

Incorrect tightening bends the ring steel and navy. Follow these steps strictly:

Maximum tightening torque: 35 NM – 40 nm.

Tool: Use Always Dynamometric Key. Not advisable to use impact pistols.

The ring NOT you must touch the metal of the wheel rim; Its function is to compress the rubber tyre. If you squeeze “to the bottom”, he will bend the hoop.

Progressive installation (star pattern):

Manual adjustment: Present all screws by hand.

1st last (15 nm): Tighten following a cross pattern (jumping the opposite).

2nd passed (30 nm): Repeat the cross pattern.

Final adjustment (35-40 nm): Final tightening and circular verification.

Service: Re-tighten the 50 km of use, since the heel of the tyre it sits and the screws can lose tension.
